DESCRIPTION

Basic Info

Model NO.	CW-800BFS
Speed	250PCS/Min
Continuous-Rolled	No
Sealing & Cutting	Heat-Sealing Heat-Cutting
Layer	Single
Machine Type	Bag Forming Machine
Computerized	Computerized
Type	Plastic Bag Making Machine
Weight	2600kg
Power	22kw
Container	40gp
Transport Package	Wooden Pallet and Stretch Film Wrapping
Specification	8m(L)*2.8m(W)*2.0m(H)
Trademark	CHOVYTING
Origin	China
HS Code	847778000
Production Capacity	400sets/Year

Product Description

Brief Introduction:
This machine is specially design for making wicketer bag automatic.
It shows the best technic of servo motor and the latest type of mechanism structure.
CW-800BFS wicketer machine has the excellent speed of 250pcs/min.

Features:
1.Special servo motor driving
2.Germany SICK photocell
3.Rotary-arm unit for collecting bags
4.Double swing arm dancing,it is suitable for high-speed feeding,the film will not shake
5.Puncher and collect table with linkage tracking device

Optional:
1.Handle hole puncher device
2.Square bottom puncher device for bread bag
3.Round bottom punch device for chicken bag
4.zipper sealing device
5.Hotmelt glue device

Technical data:

Model	CW-800BFS	CW-1000BFS
Materail	HDPE.LDPE or PP plastic film	HDPE,LDPE or PP plastic film
unwind width	750mm(after folding)	950mm(after folding)
triangle folding	1500mm(before width)	1500mm(before width)
Bag Length	350-750mm	350-950mm
Bag width	100-350mm	100-350mm
Bottm gusset	30-60mm	30-60mm
Film thickness	0.03-0.055mm	0.03-0.055mm
Feeding speed	70m/min	70m/min
Cutting speed	250pcs/min(max)	250pcs/min(max)
zipper bag making speed	100pcs/min	pcs/min

round bottom gusset device:
1. More thin round disc bottom gusset

2. U style mould bottom molding for bottom gusset
Hole punch from top
1. 2 pcs hole punch from top of bag, our standard diameter of punch is ¢14mm
2. With EPC control for hole punch
3. With 2pcs easy tearing punch from top of hole
Photocell of printing and preheating :
Printing image tracking adopts photocell from SICK FROM GERMANY
2. The photocell of priting together with high technical computer ,
3. The pre-sealing knife is designed specially of bottom four layers film, high speed produce bag
4. Double sides heating, double cylinder driven, strong for gusing, and strong for sealing .
Collect device
1. Automatic windmill style rotary-arm collect finish bag
2. Manual drive rotary-arm, the speed change follow main motor
3. take up of collect bag pin is 2kw servo motor used YASKAWA FROM JAPAN
